Icom IC-2730E Instruction Manual page 7

8 MONITOR•DUPLEX KEY [DUP MONI]
z Push to turn the Monitor function ON and OFF. (p. 27)
z Hold down for 1 second to display the duplex direction
setting screen. (p. 50)
9 OUTPUT POWER•DTMF KEY [LOW DTMF]
z Push to select the transmit output power level. (p. 26)
z Hold down for 1 second to enter the DTMF Menu
mode. (p. 54)
10 MEMORY WRITE KEY [MW]
In the VFO mode
z Push to display the Memory write screen. (p. 30)
z Hold down for 1 second to store the operating
frequency into a blank Memory channel. (p. 31)
In the Memory mode
z Push to display the Memory entry screen. (p. 31)
11 MENU LOCK KEY [MENU
z Push to enter the MENU mode.
z Hold down for 1 second to turn the Lock function ON
or OFF.
]
PANEL DESCRIPTION
■ Controller — Display
1 2 3 4
1 MAIN ICON
Displayed on the MAIN band. (p. 23)
• You can transmit on only the MAIN band.
• The MENU mode settings are for the MAIN band.
2 TX ICON (p. 26)
Displayed while transmitting.
3 DUPLEX ICON (p. 50)
Displayed while in the duplex mode.
4 TONE ICONS (p. 56)
5 Bluetooth ICON (p. 74)
Displayed when you make a Bluetooth connection
between your transceiver* and a Bluetooth headset.
* Requires the optional UT-133A Bluetooth
6 KEY LOCK ICON (p. 25)
Displayed when the Lock function is ON.
7 FREQUENCY READOUT (pp. 9, 24)
Displays the operating frequency, MENU item, and so on.
5 6
7
installed.
unit
1
1
2
