Icom IC-2730E Instruction Manual page 35

■ Writing into a Memory or Call channel
After setting a frequency in the VFO mode, you can write it
into your desired channel or an automatically selected blank
channel.
Memory channels 002 ~ 999 are blank as the default.
Memory channels are independently selectable on both the
left and right bands.
LThe operations are for the MAIN band.
D Writing into the selected channel
Example: Writing 434.100 MHz into Memory channel "11."
1. Push [V/MHz SCAN]S.
• Selects the VFO mode.
2. Set the operating frequency to 434.100 MHz.
3. Push [MW]C.
• "MR" blinks.
Blinks
4. Rotate [DIAL] to select "CH SEL."
S
5. Push [ï]D.
• Displays the Channel select screen.
• Push [◄]D to go back to the previous tree level.
MEMORY OPERATION
6. Rotate [DIAL] to select channel "11."
S
NOTE: If you select a pre-entered channel, the
previous channel content will be displayed.
• You can also select Call channels.
• To select Bank channel, hold down [MAIN BAND]S for 1 second.
7. Push [ï]D.
8. Rotate [DIAL] to select "WRITE."
S
9. Push [ï]D.
• Displays "WRITE?."
• When you select a pre-entered channel in step 6, "OVERW?"
is displayed.
10. Rotate [DIAL]S to select "YES."
11. Push [ï]D.
• Beeps sound.
• Writes into the selected channel, and returns to the VFO mode.
4
4
Select
30
