Icom IC-2730E Instruction Manual page 63

D Setting the Tone frequency
1. Push [MENU ]C.
• Enters the MENU mode.
2. Rotate [DIAL]S to select "C TONE" (TSQL Freq).
3. Push [ï]D.
• Goes to the next tree level.
4. Rotate [DIAL]S to select a desired tone frequency.
Selectable options: 67.0 Hz ~ 254.1 Hz
5. Push [ï]D.
• Sets the selected option, and goes back to the previous tree level.
6. Push [MAIN BAND]S.
• Exits the MENU mode.
D isplay
S ide C enter S ide
The C, S, or D in the
instructions indicate the
area of the controller.
C: Center
S: Side
D: Display
OTHER FUNCTIONS
D Setting the Repeater Tone frequency
1. Push [MENU ]C.
• Enters the MENU mode.
2. Rotate [DIAL]S to select "R TONE" (Repeater Tone).
3. Push [ï]D.
• Goes to the next tree level.
4. Rotate [DIAL]S to select a desired tone frequency.
Selectable options: 67.0 Hz ~ 254.1 Hz
5. Push [ï]D.
• Sets the selected option, and goes back to the previous tree
level.
6. Push [MAIN BAND]S.
• Exits the MENU mode.
