Icom IC-2730E Instruction Manual page 56

7
REPEATER AND DUPLEX OPERATIONS
■ Duplex operation
D Duplex operation
1. Push [MONI DUP]
to check whether another station is transmitting on it,
or not.
• The transceiver transmit frequency is displayed.
2. Push [MONI DUP]
operate normally.
NOTE: When the Auto repeater function is ON, and the
operating frequency is set out of the repeater output
frequency range, the duplex mode is automatically cancelled.
D isplay
S ide C enter
51
to listen to the transmit frequency
C
again to stop monitoring, and then
C
The C, S, or D in the
instructions indicate the
area of the controller.
C: Center
S: Side
S ide
D: Display
■ Off band indication
If the transmit frequency is out of the amateur band, the off
band indication "OFF" is displayed when [PTT] is pushed.
Check the frequency offset or duplex direction in this case.
(p. 50)
Displayed
