Icom IC-2730E Instruction Manual page 38

4
MEMORY OPERATION
■ Setting a Memory bank
D Directly entering into a Memory bank
You can also enter the memory content directly into a
memory bank channel. This way is a short cut to creating a
memory channel, and then assigning it to a bank.
In that case, the transceiver automatically selects the lowest
blank memory channel, to enter content into.
Example: Writing 434.100 MHz into Bank group "A."
1. Push [V/MHz SCAN]S.
• Selects the VFO mode.
2. Set the operating frequency to 434.100 MHz.
3. Push [MW]C to display the Memory write screen.
4. Rotate [DIAL]
S
5. Push [ï]D.
6. Rotate [DIAL]
S
7. Push [ï]D.
8. Rotate [DIAL]
S
9. Push [ï]D.
• Displays "WRITE?."
10. Rotate [DIAL]
S
11. Push [ï]D.
• Sounds beeps, writes the memory content to the bank
channel, and returns to the VFO mode.
33
to select "BANK."
to select a Bank group "A."
Select
to select "WRITE."
to select "YES."
D Selecting the Memory bank mode
When you select the Memory bank mode, rotating [DIAL]S
selects only the bank channels assigned to the selected bank.
1. Push [MR CALL]S.
• Selects the Memory mode.
2. Hold down [MAIN BAND]S for 1 second.
3. Rotate [DIAL] to select a desired Bank group.
S
• Displays the Bank name, if entered.
4. Push [MAIN BAND]S.
• Selects the Memory bank mode.
5. Rotate [DIAL] to select a desired Bank channel.
S
• Blank channels are not displayed.
• To return to the Memory channels display, select a Memory
channel in step 3.
D isplay
S ide C enter S ide
The C, S, or D in the
instructions indicate the
area of the controller.
C: Center
S: Side
D: Display
