Icom IC-2730E Instruction Manual page 54

7
REPEATER AND DUPLEX OPERATIONS
■ Repeater operation
For your reference:
• If the Repeater tone frequency or the frequency offset
is changed, the tone or offset for the Auto Repeater
function is also changed.
• If the offset value will cause the transmit frequency to be
out of the band, "OFF" will be displayed when [PTT] is
pushed, and transmit will be inhibited. (p. 51)
D Checking the repeater input signal
You can check whether another station's transmit signal can
be received directly or not, by listening to the repeater input
frequency.
z Push [MONI DUP]C to listen on the repeater input
frequency.
• While monitoring, "BUSY" blinks.
• While monitoring, the displayed frequency automatically
changes to the transceiver transmit frequency (repeater input
frequency).
• When the other station's signal can be directly received, move
to a non-repeater frequency and use simplex. (Duplex OFF)
• While monitoring, the Attenuator function is temporarily
disabled to receive a weak signal.
While monitoring
49
D 1750 Hz tone burst
A 1750 Hz tone is required to access many European
repeaters.
L This function can be used only when the supplied HM-207
microphone or the optional HM-154/HM-209/HM-232 microphone
is connected.
1. Select the FM mode. (p. 26)
2. Push [PTT] on the microphone to transmit, and then
push the key that the "T-CALL" function is assigned to
access the repeater with a short tone burst.
LSee page 8 for microphone key assignment details.
3. Operate normally.
• The S/RF meter displays the output power level.
Sending the tone burst
D isplay
S ide C enter S ide
The C, S, or D in the
instructions indicate the
area of the controller.
C: Center
S: Side
D: Display
