Icom IC-2730E Instruction Manual page 68

9
INSTALLATION AND CONNECTIONS
■ Connecting the controller to
the main unit
Connect the controller to the main unit with the supplied
control cable.
• The following longer cables may be required, depending on the
installation location.
OPC-440
mic extension cable
OPC-647
mic extension cable
OPC-1156
controller extension cable
SP-35
external speaker
SP-35L
external speaker
SP-30
external speaker
Main unit
6-pin connector
D When using the MBA-4 combination bracket
When using the MBA-4
the controller and the main unit.
1. Unplug the 6-pin connector from the controller and the
main unit.
2. Attach the MBA-4 to the controller's rear panel with the
supplied two screws (M2.6 × 6) as shown to the right.
3. Connect the supplied connector to the controller's rear
panel as shown to the right.
63
: 5 m (16.4 ft)
: 2.5 m (8.2 ft)
: 3.5 m (11.4 ft)
: 2 m (6.5 ft)
: 6 m (19.6 ft)
: 2.8 m (9.1 ft)
Controller (Rear)
6-pin connector
, you can unify
combination bracket
MBA-4
Screw*
Projection tab
Cable*
4. Connect the other side of connector to the main unit.
5. Insert the MBA-4's projection tabs into the main unit. (1)
6. Slide the MBA-4 to the left. (2)
1
■ Connecting a microphone
Plug in the microphone to the microphone jack on the main
unit or controller as shown below.
To the main unit
Controller (Rear) Microphone
Main unit
Controller (Rear)
* Supplied with the MBA-4
2
To the controller
Microphone
Controller
