Icom IC-2730E Instruction Manual page 31

■ Transmitting
Before transmitting, monitor the operating frequency
to see if other stations are on the frequency.
CAUTION: Transmitting without an antenna may damage
the transceiver.
L You can transmit on only the 144 MHz and 430 MHz
bands, and on the MAIN band.
1. Push [LOW DTMF]C to select the output power level.
Selectable levels: Low, Mid, and High
• "LOW" is displayed when you select low power.
• "MID" is displayed when you select mid power.
• No icon is displayed when you select high power.
• Lower output power during short-range communications may
reduce the possibility of interference to other stations.
2. Hold down [PTT] to transmit, and speak at your normal
voice level.
• The S/RF meter displays the output power level.
3. Release [PTT] to receive.
D isplay
S ide C enter S ide
The C, S, or D in the
instructions indicate the
area of the controller.
C: Center
S: Side
D: Display
■ Selecting the operating mode
The transceiver has a total of four operating modes, AM,
AM-N, FM and FM-N. (Default: FM)
In the AIR band, the AM mode is set as a default. If the "AIR"
(AIR band display) item is set to "CH ID" in EXMENU, you
cannot select the operating mode.
L You can independently set the left and right bands when
they are selected as the MAIN band.
1. Push [MAIN BAND]S of the band that the operating
mode is set to.
2. Push [MENU
]C.
• Enters the MENU mode.
3. Rotate [DIAL]S to select "MODE" (Operating mode).
4. Push [ï]D.
• Goes to the next tree level.
5. Rotate [DIAL]S to select the desired operating mode.
Selectable options:
In the 144 or 430 MHz band: FM or FM-N
In the AIR band:
• While in the FM-N mode, the TX modulation is automatically
set to approximately 2.5 kHz.
6. Push [ï]D.
• Sets the selected option, and goes back to the previous tree level.
7. Push [MAIN BAND]S.
• Exits the MENU mode.
BASIC OPERATION
AM or AM-N
