Electrical Connectors, IMS5420IP67
General Rules
As a matter of principle, avoid:
- any contamination of the connector, e.g., dust or
finger prints
- unnecessary mating cycles.
- any mechanical stress of the optical fiber (bending,
crushing, pulling, twisting, knotting etc.).
- tight curvature of the optical fiber because the glass
fiber is damaged in the process and this causes per-
manent damage.
Never bend the cable more tightly than the permissible
bending radius.
Mounting, Mounting Adapter
The sensors use an optical measuring principle that
allows for measurements in the nm range.
i
Ensure careful handling during installation and
operation.
Mount the sensors with an outer clamp. Use the
MA5400-10 mounting adapter from the optional
accessories.
This type of sensor installation ensures the highest level
of reliability because the sensor's cylindrical cover is
clamped over a relatively large area.
IMS5420-TH / IMS5420MP-TH / IMS5420IP67-TH / IMS5420IP67MP-TH
Fixed:
R = 30 mm or more
Flexible:
R = 40 mm or more
Electrical Connectors, IMS5420IP67
Supply Voltage
Pin Color Comment
1 Brown +U
B
24 VDC ± 15 %,
I < 1 A
max
3 Blue GND
Optional accessory: PC5420/IP67-x
Ethernet
5-pin M12 female connector
with D coding
Optional accessory:
shielded SC5420IP67-IE-x-RJ45
Ethernet cable
RS422
Pin Color Name
1 Yellow RX -
2 Green RX +
3 Grey GND422
4 Pink TX +
5 Brown TX -
Optional accessory: SC5420IP67-OE-x
Wire colours correspond to the optional accessory cables.
4-pin M12 connector
5-pol M12 Buchse
