Thickness Measurement, Web Page Display
In the window on the left, the signals can be enabled or disabled both during and after the measurement. Inactive
2
graphs are gray. Click on the check mark to add them. The changes take effect when saving the settings. Use
the eye symbols
• 01PEAK01: Chronological sequence of displacement signal
Auto (= automatic scaling) or Manual
3
(= manual setting) allow for scaling the measurement axis (Y axis) of the graphic.
4 The current values for distance, exposure time, current measuring rate and time stamp are displayed in the text
boxes above the graphic. Errors are displayed as well.
5 Mouseover feature. When moving the mouse over the graph, curve points are highlighted with a circle symbol
while the corresponding values are displayed in the text boxes above the graph.
6 X axis scaling: The total signal is zoomable with the slider on the left side during running measurement. The time
range can be defined in the input field below the time axis. If the diagram is stopped, you can also use the right
slider. The zoom window can also be moved with the mouse in the center of the zoom window (arrow cross).
7 The LED visualizes the status of the transmission
of measured values:
- green: transmission of measured values is running.
- yellow: waiting for data in trigger mode
- gray: transmission of measured values stopped
Data queries are controlled by using the Play/Pause/Stop/Save buttons of the measured values that were
transmitted. Stop stops the diagram; data selection and zoom function are still possible. Pause interrupts
recording. Save opens the Windows selection dialog for file name and storage location to save the FFT signals
resp. measurement values in a CSV file (separation with semicolon).
Click the button
8 The two buttons allow to switch between FFT signal and measurement representation.
IMS5420-TH / IMS5420MP-TH / IMS5420IP67-TH / IMS5420IP67MP-TH
to show and hide the single signals. The calculation continues in the background.
(Start), for starting the display of the measurement results.
