MICRO-EPSILON interferoMETER IMS5420 Quick Manual page 4

General
Avoid shocks and impacts to the sensor and the controller.
NOTICE
> Damage to or destruction of the components
Never kink optical fibers or bend them in thight radii.
> Damage to or destruction of the optical fibers; failure of measurement device
Protect the ends of the optical fibers against contamination
> Failure of the measuring device
Protect the cable against damage.
> Failure of the measuring device
Intended Use
- The interferoMETER measuring system is designed for use in an industrial environments and domestic areas.
It is used for measuring thickness and surface inspection, monitoring quality and checking dimensions.
- The measuring system must only be operated within the limits specified in the technical data, see operating instruc-
tions chap. 3.
- The measuring system must be used in such a way that no persons are endangered or machines and other
material goods are damaged in the event of malfunction or total failure of the controller.
- Take additional precautions for safety and damage prevention in case of safety-related applications.
Proper Environment
Model
Protection
class
Controller
Storage
Temperature
Operation Sensor +10 ... +50 °C (+50 ... +122 °F), front side
range
Operation Controller
Humidity
IMS5420-TH / IMS5420MP-TH / IMS5420IP67-TH / IMS5420IP67MP-TH
IMS5420-TH
Sensor
IMS5420MP-TH
IP65 (optional IP67)
IP 40
-20 ... +70 °C (-4 ... +158 °F)
+10 ... +50 °C (+50 ... +122 °F)
5 – 95 % (non-condensing)
IMS5420IP67-TH IMS5420IP67MP-TH
IP 67
+10 ... +60 °C (+50 ... +140 °F), front side
Page 4
