MICRO-EPSILON interferoMETER IMS5420 Quick Manual page 11

LED IMS5420IP67
Button Multifunction, IMS5420
The Multifunction button of the controller has multiple functions. It enables, e.g., to operate the light source.
The button is factory-set to the Pilotlaser on/off feature.
Key function
1 / 2
There are two defined time intervals for pressing the button; each of these can be assigned a function. All time inter-
vals are indicated by the LEDs flashing/lighting up.
Function 1
Master value
Pilot laser
SLED
0 2 sec
flashes off
slowly
IMS5420-TH / IMS5420MP-TH / IMS5420IP67-TH / IMS5420IP67MP-TH
Set / reset
Starts or stops the master measurement of the selected signals
master value
Pilot laser Turns on/off the pilot laser
SLED Turns the light source on/off for the sensor
Inactive Key has no function
Function 2
5 sec 10 sec
flashes both
slowly off
Factory
setting
15 sec x min time
green off both on
on
Key
lock
The Intensity and
Range LEDs indicate
the currently selected
function.
Multifunction Button
Actuation Time
Page 11
