Initial Operation
Presets, Measurement Configuration
Common measurement configurations (presets) for various target surfaces are stored on the controller. This allows
you to quickly start with your individual measurement task. In a preset the basic features like peak or material selec-
tion and calculation functions are already set.
When saving a modified preset, the web interface displays a dialog for entering a setup name. This prevents presets
from being overwritten by accident. Data output only starts when the associated interface is activated.
Preset
IMS5420IP67
Overview possible presets
IMS5420-TH / IMS5420MP-TH / IMS5420IP67-TH / IMS5420IP67MP-TH
IMS5420 IMS5420MP
IMS5420IP67MP
• •
• •
•
The signal quality is set to Balanced at the
factory.
Go to the Home > Measurement configu-
ration menu and start the Measurement
configuration.
Select a configuration.
Then, you can apply your own settings (setups).
Preset
IMS5420IP67
•
possible preset
IMS5420 IMS5420MP
IMS5420IP67MP
•
•
