MICRO-EPSILON interferoMETER IMS5420 Quick Manual page 10

LEDs Controller
LEDs Controller
Power on Green
Off
Status
If EtherCAT is active, meaning of the LED is conform with the Ether-CAT guide-
lines.
Red
Yellow
Green
Red
Yellow
Green
Yellow flashing SLED current outside the optimal value range
Red
Green
Green
Red
Yellow
Green
1) When measuring outside the optimum current value of the SLED, the controller will
measure, but the measurement accuracy may not be as specified.
IMS5420-TH / IMS5420MP-TH / IMS5420IP67-TH / IMS5420IP67MP-TH
Supply voltage available
No error
Signal in saturation
Signal too low
Signal ok
SLED of
SLED warms up
SLED ready for operation
Pilot laser off
Pilot laser on
Pilot laser is alternately turned on and off,
if no target object or outside the measuring range
No target object, or target object outside the operating range.
The expected number of peaks was not found or it was not
possible to assign a thickness.
Target close to mid of working distance
Target within operating range
The expected number of peaks was found. A valid thickness
could be found for each peak.
LED IMS5420IP67
Power on
Supply voltage available
1
Green
