Chapter 1 Cisco NAC Appliance Hardware Platforms
NAC-3315 Serial Number Location
The serial number label is located at the lower left of the front-panel of the NAC-3315. (See
Figure 1-1
The serial number for the NAC-3315 is 7 characters long. You can also view the NAC-3315 serial
Note
number location on the Cisco Support website using the Cisco Product Identification Tool. For details,
see
Cisco NAC-3315 Front and Rear Panels
The Cisco NAC-3315 platform is recommended for Clean Access Lite Manager and Clean Access Server
(100/250/500 user count) deployments. A NAC-3315 CAM Lite can manage up to 3 Clean Access
Servers or 3 HA-CAS pairs. A NAC-3315 CAS can support 100, 250, or 500 users.
FIPS 140-2 compliant NAC-3315 CAS can support only 250 or 500 users.
Note
The Cisco NAC-3315 comes equipped with 4 network interfaces to provide flexibility in NIC interface
selection and to facilitate CAS high availability configuration.
For additional details, see

Front Panel Features

Figure 1-2
1
2
3
OL-20326-01
NAC-3315 Appliance Serial Number Location
Cisco Product Identification Tool, page
FIPS 140-2 Compliant and Non-FIPS Hardware Platforms, page
Cisco NAC-3315 Front Panel
1
2
5
Front USB port 1
Front USB port 2
Hard disk drive (HDD) bay 0
Cisco NAC 3315 Series
1-27.
3 4
4
Hard disk drive (HDD) bay 2
5
CD-ROM/DVD drive
Cisco NAC Appliance Hardware Installation Guide
NAC-3315, NAC-3355, and NAC-3395
Figure
XXXXNNNNNNN
NAC Manager
CISCO
1-1.
Cisco NAC 3315 Series
CISCO
NAC Manager
1-1.)
1-5
