NAC-3315, NAC-3355, and NAC-3395
NAC-3355 Serial Number Location
The serial number label is located at the lower left of the front-panel of the NAC-3355. (See
Figure 1-6
Note The serial number for the NAC-3355 is 7 characters long. You can also view the NAC-3315 serial
number location on the Cisco Support website using the Cisco Product Identification Tool. For details,
see
Cisco NAC-3355 Front and Rear Panels
The Cisco NAC-3355 FIPS 140-2 compliant platform provides enhanced capability for enterprise wide
Clean Access Standard Manager and Clean Access Server (1500/2500/3500 user count) deployments. A
NAC-3355 Standard CAM can manage up to 20 Clean Access Servers or 20 HA-CAS pairs. A
NAC-3355 CAS can support up to 1500, 2500, or 3500 users.
Similar to the Cisco NAC-3315, the Cisco NAC-3355 comes equipped with 4 network interfaces to
provide flexibility in NIC interface selection and facilitate CAS high availability configuration. The
Cisco NAC-3355 additionally provides 2 GB of RAM, two SAS drives configured in RAID 0 and 1, dual
power supplies, and an SSL accelerator card to support large network deployments and provide added
reliability for a centralized CAM/CAS deployment in the network core.
For additional details, see
Front Panel Features
Figure 1-7
1
2
3
4
Cisco NAC Appliance Hardware Installation Guide
1-8
NAC-3355 Appliance Serial Number Location
XXXXNNNNNNN
Cisco Product Identification Tool, page
FIPS 140-2 Compliant and Non-FIPS Hardware Platforms, page
Cisco NAC-3355 Front Panel
1 2
13 12
Hard disk drive (HDD) bay 0
Empty (unused) hard disk drive (HDD) bay
Empty (unused) hard disk drive (HDD) bay
Power button with LED indicator (bicolor:
green/amber)
Chapter 1
1-27.
3 4 5
10
11
8
Front USB port 1
9
1
Front USB port 2
10
1
CD-ROM/DVD drive
11
Empty (unused) hard disk drive (HDD) bay
Cisco NAC Appliance Hardware Platforms
Figure
Cisco NAC 3355 Series
NAC Manager
CISCO
1-1.
6 7 8
Cisco NAC 3355 Series
NAC Manager
CISCO
9
1-6.)
1
