NAC-3310, NAC-3350, and NAC-3390
7
8
9
10
11
12
13

Cisco NAC-3390 Front and Rear Panels

The Cisco NAC-3390 is only FIPS-compliant after you have purchased and installed a field-replaceable
Note
FIPS card as described in the
Guide.
The Cisco NAC-3390 Appliance platform provides the enhanced processing, memory, and power
necessary for enterprise wide deployment of the Clean Access Super Manager (Super CAM) which can
support up to 40 Clean Access Servers or 40 HA-CAS pairs. The Cisco NAC-3390 features dual
processors, dual power supplies, 4 GB of RAM, 4 hard disk drives, two integrated NICs, and an SSL
accelerator. For additional details, see
page
The Super CAM software is supported only on the Cisco NAC-3395 and Cisco NAC-3390 platforms.
Note
Cisco NAC Appliance Hardware Installation Guide
1-24
10/100/1000 NIC 1 (Broadcom)
Activity LED
10/100/1000 NIC 1 (Broadcom) Link
LED
10/100/1000 NIC 2 (Broadcom)
Activity LED
10/100/1000 NIC 2 (Broadcom) Link
LED
UID button/LED
Power supply 1 LED
Power supply 2 LED
Cisco NAC Appliance FIPS Card Field-Replaceable Unit Installation
1-1.
Chapter 1
Green = Activity exists
Flashing green = Activity exists
Off = No activity exists
Green = Link exists
Off = No link exists
Green = Activity exists
Flashing green = Activity exists
Off = No activity exists
Green = Link exists
Off = No link exists
Blue = Identification is activated
Flashing blue = System is being managed remotely
Off = Identification is deactivated
Green = Normal
Off = System is off or power supply has failed
Green = Normal
Off = System is off or power supply has failed
FIPS 140-2 Compliant and Non-FIPS Hardware Platforms,
Cisco NAC Appliance Hardware Platforms
OL-20326-01
