Chapter 1 Cisco NAC Appliance Hardware Platforms
1
2
3
4
5
6
7
8
9
OL-20326-01
FIPS card status LED
NIC 1 (eth0) activity LED
NIC 1 (eth0) link LED
AC power LED
DC power LED
Power supply error LED
System error LED
Rear Locator LED
Power LED
Solid blue occasionally blinking off = FIPS card is enabled and
accepting commands
Two short blue flashes followed by a pause = FIPS card is in
initialization mode
Two longer blue flashes followed by a pause = FIPS card is in
maintenance mode
Repeatedly flashing morse code distress call (. . . - - - . . .)—three
short blue flashes followed by three longer blue flashes followed
again by three more short blue flashes = FIPS card is in error mode
Off = There is no power source connected to the FIPS card
Green = Activity exists
Flashing green = Activity exists
Off = No activity exists
Green = Link exists
Off = No link exists
Green = AC power source is connected to power supply
Off = No AC power source is connected to power supply
Green = DC power source is connected to power supply
Off = No DC power source is connected to power supply
Amber = Power source to power supply is present, but power
supply is in error state
Off = Power supply is functioning normally (if AC and DC power
indicators are green) or power supply is disconnected
Amber = Indicates that a system error has occurred
Off = The system is functioning normally
Flashing blue = The Front Locator button has been pressed
Green = The appliance has AC power and is powered up
Rapidly flashing green = The appliance is off and is not yet ready
to be turned on (the appliance typically only remains in this state
for 1 to 3 minutes)
Slowly flashing green = The appliance is currently off and ready
to be turned on
slowly fading on/off green = The appliance is in power-save mode
and is ready to be turned on
Off = The appliance is powered off (power is disconnected)
Cisco NAC Appliance Hardware Installation Guide
NAC-3315, NAC-3355, and NAC-3395
1-11
