Appendices
General
Status
Code (hex)
2B Unknown Modbus Error
2C Attribute not gettable
2D Instance Not Deletable
2E Service Not Supported for
Specified Path
2F-CF
D0-FF Reserved for Object Class
and service errors
A-8-2
Extended Status Codes
General
Status
(hex)
01 0100
01 0103
01 0105
01 0106
01 0107
01 0108
01 0109
01 0110
01 0111
01 0112
01 0113
01 0114
01 0115
01 0116
01 0117
01 0118
01 0119
01 011A
01 011B
01 011C
A-80
Status Name
A CIP to Modbus translator received an unknown Modbus Exception
Code.
A request to read a non-readable attribute was received.
The requested object instance cannot be deleted.
The object supports the service, but not for the designated applica-
tion path (e.g. attribute).
NOTE: Not to be used for any set service (use General Status Code
0x0E or 0x29 instead)
Reserved by CIP for future extensions.
This range of error codes is to be used to indicate object class-spe-
cific errors. This code range is used only when none of the error co-
des in this table accurately reflect the error that occurred. The addi-
tional code field is used to describe the general error code in more
detail.
Additional
Status
(hex)
Connection in use or duplicate forward open.
Transport class and trigger combination not supported.
Ownership Conflict or OUNID Mismatch. The configuration is already owned by
another originator.
Ownership Conflict or OUNID Mismatch. The output connection was already
owned by another originator.
Connection not found at target application.
Invalid connection type. There is a problem with either the connection type or pri-
ority of the connection.
Invalid connection size.
Device not configured.
RPI not supported. May also indicate problem with connection time-out multiplier,
or production inhibit time.
RPI VALUE(S) not acceptable
Connection Manager cannot support any more connections.
Either the vendor ID or the product code in the key segment does not match the
device.
Device type in the key segment does not match the device.
Major or minor revision information in the key segment does not match the de-
vice.
Invalid connection point.
Invalid configuration format.
Connection request failed because there is no controlling connection currently
open.
Target application cannot support any more connections.
RPI is smaller than the production inhibit time.
Transport Class not supported
NX-series Safety Control Unit/Communication Control Unit User's Manual (Z395)
Description of Status
Explanation
