3
Check the CRC data, and click theOKButton.
The program is imported and added to the project.
Precautions for Correct Use
After a function block is imported, the safety program in the project will be in an unvalidated
state. Always execute safety validation again.
Additional Information
You can check the CRC data on theChange TrackingTab Page or Properties Dialog Box.
Exporting User-defined Function Blocks
You can export a user-defined function block to a file (extension .sfb).
You can import the exported user-defined function block to reuse it in another project.
Use the following procedure.
1
Right-click the user-defined function block under Programming - POUs - Function Blocks in
the Multiview Explorer and select Export from the menu.
The Export Dialog Box is displayed.
2
Enter a file name, and then click the Save Button.
A function block file with an .sfb extension is saved.
NX-series Safety Control Unit/Communication Control Unit User's Manual (Z395)
8 Programming
8
8-33
