8 Programming
The following Simple Automatic Test Tab Page is displayed.
The setting areas of the Simple Automatic Test are configured as described in the following table.
Item Name
(a) Simple
Auto-
matic
Test Op-
eration
Panel
8-106
(a)
(b)
(c)
(d)
(e)
The operation panel is used to make settings for and execute the Simple Automatic Test. You
can perform the following operations.
Run Button
Test Result Button
Register Variables Button
Initial Value Settings Button Displays the Initial Value Settings Dialog Box.
Feedback Settings Button
NX-series Safety Control Unit/Communication Control Unit User's Manual (Z395)
Function
Executes the Simple Automatic Test.
Shows the previous test results for the Simple Automatic Test.
Used to register the variables that are used for the Simple Au-
tomatic Test.
Displays the Feedback Settings Dialog Box.
