Appendices
Objects tab
Type Name
APP
TASK
PRG
FB
GVL
MAP
CNF
Devices tab
Type Name
SAFEPLC
SAFEDEV
XVARDEF
Pin Operations
This section describes the procedures to create and delete pins, and the jump function.
l Creating Pins
When you click the Pin project Button, a dialog box to enter the current status name is displayed.
The name that you set is shown as the pin information in the upper part of the Change Tracking
Tab Page.
If the data changes from the data that is in effect at this point, the contents of the change are dis-
played in the tab page.
l Deleting a Pin
When you click the Clear Pin Button, the status that you created with the Pin project Button is
deleted.
l Jump Function
When you double-click information on the Change Tracking Tab Page, the global variable table,
FBD editor, or other corresponding tab page is displayed.
A-68
Safety Application
Safety Task
Programs
Function Blocks
Global Variables
I/O Map and exposed variables
Safety process data communications
Safety CPU Unit
Safety I/O Unit
Exposed variables
NX-series Safety Control Unit/Communication Control Unit User's Manual (Z395)
