NX-SID800 Safety Input Unit
Port Data type
Standard Input WORD
1st Word
Si00 Logical Val- BOOL
ue
Si01 Logical Val- BOOL
ue
Si02 Logical Val- BOOL
ue
Si03 Logical Val- BOOL
ue
Si04 Logical Val- BOOL
ue
Si05 Logical Val- BOOL
ue
Si06 Logical Val- BOOL
ue
Si07 Logical Val- BOOL
ue
Safety Connec- BOOL
tion Status
Safety Input Ter- BOOL
minal Status
Unit Normal Sta- BOOL
tus
NX-series Safety Control Unit/Communication Control Unit User's Manual (Z395)
R/W Name
R Standard In- ---
put 1st Word
R Si00 Logical Gives the status of safety input termi-
Value nal Si00.
0: OFF, 1: ON
R Si01 Logical Gives the status of safety input termi-
Value nal Si01.
0: OFF, 1: ON
R Si02 Logical Gives the status of safety input termi-
Value nal Si02.
0: OFF, 1: ON
R Si03 Logical Gives the status of safety input termi-
Value nal Si03.
0: OFF, 1: ON
R Si04 Logical Gives the status of safety input termi-
Value nal Si04.
0: OFF, 1: ON
R Si05 Logical Gives the status of safety input termi-
Value nal Si05.
0: OFF, 1: ON
R Si06 Logical Gives the status of safety input termi-
Value nal Si06.
0: OFF, 1: ON
R Si07 Logical Gives the status of safety input termi-
Value nal Si07.
0: OFF, 1: ON
R Safety Con- This flag indicates when a safety con-
nection Sta- nection is active. Use it for an input to
tus the Activate terminal on a safety FB or
for safety connection/disconnection
applications.
R Safety Input This flag indicates the status of the
Terminal Sta- safety input terminals.
tus 0: An error has occurred on one of the
safety input terminals.
1: All of the safety input terminals are
normal (no errors).
R Unit Normal This flag indicates the status of the
Status Unit.
0: An error has occurred.
1: Normal (no errors)
Description
0000 hex
0
0
0
0
0
0
0
0
0
0
0
