15 Troubleshooting
Event name Safety Data Logging Aborted
Description The execution of safety data logging was aborted.
Source PLC Function Module
Error attributes Level
Effects User program
System-de- Variable
fined variables
_PLC_SFLogSta
Cause and cor- Assumed cause
rection
The execution of safety data log-
ging was aborted by a service
switch operation.
Either a communications error on
the safety master connections oc-
curred or the Safety CPU Unit en-
tered an operating mode where it
could not continue safety process
data communications.
The NX bus was restarted.
The Controller Setup or program
was changed.
Attached infor- Attached information 1: Setting number for the aborted logging
mation Attached information 2: The output log file name
Attached information 3: Cause for the interruption
•
1: A service switch was pressed.
•
2: Safety master connections are not established.
•
3: The NX bus was restarted.
•
4: The Controller Setup or program was changed.
•
Precautions/ The aborted safety data logging does not restart automatically even if the causes of aborting are removed.
•
Remarks
The saved log data only includes data that was logged before the occurrence of aborting, regardless of the
post-trigger ratio setting.
15-110
Source details
Observation Recovery
Continues. Operation
Data type
ARRAY[0..1] OF _sSFLOG_STA
Correction
---
Check the safety process data
communications related event that
occurred most recently, and per-
form the required actions and cor-
rections. Alternatively, change the
Safety CPU Unit operating mode
so that it can perform safety proc-
ess data communications.
---
---
NX-series Safety Control Unit/Communication Control Unit User's Manual (Z395)
Event code 90470000 hex
None Detection tim-
ing
--- Log category
Not affected.
Name
Safety Data Logging Status
Prevention
---
Make sure that safety process data
communications are not interrupted
unintentionally when you start safe-
ty data logging.
---
---
During the exe-
cution of safety
data logging
System
