Applicable Terminal Blocks for Each Model
Current capacity of power supply terminals and applicable terminal blocks for each model of Commu-
nication Control Unit are shown in the following table.
Unit model
number
NX-CSG320
Precautions for Correct Use
Current capacity of power supply terminal for NX-CSG320 is 4 A or less. Make sure that each
current rating of the Unit power supply and I/O power supply does not change if you mount an
NX-TBC082 Terminal Block that has terminal current capacity of 10 A.
NX-series Safety Control Unit/Communication Control Unit User's Manual (Z395)
Current capacity of power sup-
ply terminal for the Unit
Unit power I/O power sup-
supply ply
4 A
3 Specifications of Configuration Units
Terminal block
Number
Terminal
of termi-
block model
nals
NX-TBC082 8
Terminal
Ground ter-
current
minal mark
capacity
Provided 10 A
