Omron sysmac NX Series User Manual page 761

Event name Tag Data Link Started
Meaning Tag data links were started by the Network Configurator, Sysmac Studio, or manipulation of a system-defined
variable. Or, the data link table was downloaded from the Network Configurator or Sysmac Studio again.
Source EtherNet/IP Function Module
Error attributes Level
Effects User program
System-de- Variable
fined variables
_EIP_TDLinkStartCmd
_EIP1_TDLinkStartCmd
_EIP2_TDLinkStartCmd
Cause and cor- Assumed cause
rection
Tag data links were started by the
Network Configurator, Sysmac Stu-
dio, or manipulation of a systemde-
fined variable.
Attached infor- Attached information 1: Controller status (01 hex: PROGRAM mode, 02 hex: RUN mode)
mation Attached information 2: Operation method 01 hex: Operation from the Network Configurator or Sysmac Studio,
02 hex: Operation with system-defined variable
Precautions/ None
Remarks
Event name Link Detected
Meaning Establishment of an Ethernet link was detected.
Source EtherNet/IP Function Module
Error attributes Level
Effects User program
System-de- Variable
fined variables
None
Cause and cor- Assumed cause
rection
Establishment of an Ethernet link
was detected.
Attached infor- None
mation
Precautions/ None
Remarks
NX-series Safety Control Unit/Communication Control Unit User's Manual (Z395)
Source details
Information Recovery
Continues. Operation
Data type
BOOL
BOOL
BOOL
Correction
---
Source details
Information Recovery
Continues. Operation
Data type
---
Correction
---
15 Troubleshooting
Event code 94040000 hex
CIP /CIP1 /CIP2 Detection tim-
ing
--- Log category
Not affected.
Name
Tag Data Link Communications
Start Switch
CIP Communications1 Tag Data
Link Communications Start Switch
CIP Communications2 Tag Data
Link Communications Start Switch
Prevention
---
Event code 94050000 hex
Communica- Detection tim-
tions port, com- ing
munications port
1, or communi-
cations port 2
--- Log category
Not affected.
Name
---
Prevention
---
At user opera-
tion
Access
15
When links are
established
System
15-161
