The relation between the working distance and the field of view is listed below.
Field of view (mm)

Table 10: The Relation between the Working Distance and the Field of View

5. Electrical Interface

5.1 Overview

This chapter introduces all electrical interfaces of the robot arm and control box.

5.2 Electrical Warnings and Cautions

The application design and installation of the robot should comply with the following warnings.
DANGER:
1. Ensure all pieces of the equipment are kept dry. If water enters the equipment, disconnect
the power and contact your supplier.
2. Only use the original cables included with the robot. If you need longer cables, contact
your supplier.
3. Ensure that the robot is properly grounded. If the grounding is not correct, it may cause a
fire or electric shock.
WARNING:
The I/O cables used for the link between the control box and other pieces of equipment
should not be longer than 30 meters, unless testing shows that longer cables are feasible.
Working distance (mm)
Width
Height
300 100
281.6 96.9
211.2 72.7
