Appendix A. Technical Specifications

Model
Weight
Maximum Payload
Reach
J1,J2,J4,J5,J6
Joint Range
J3
J1, J2
J3
Joint Speed
J4, J5
J6
Repeatability
Degrees of Freedom
Control Box
I/O Ports
Tool Conn.
I/O Power Supply
IP Classification
Power Consumption
Temperature
Power Supply
I/O Interface
Communication
Programming Environment
Certification
AI & Robot Vision
AI Function
Application
Positioning Accuracy
Eye in Hand (Built in)
Eye to Hand (Optional)
TM14S TM12S TM14S-M
33 kg 33.3 kg
14 12
1100 1300
+/- 159° +/- 162°
Digital In: 16 / Digital Out: 16
Analog In: 2 / Analog Out: 2
Digital In: 3 / Digital Out: 3
DO_0 (DO-0/AI) / DO_1 (DO-1/RS485-) / DO_2 (DO-2/RS485+)
24V 2.0A for control box and 24V 1.5A for tool
IP54 (Robot Arm);
IP54 (Control Box)
Rating power (AC): 450 watts
Rating power (DC): 260 watts
The robot can work in a temperature range of 0 to 50°C
100 to 240 VAC, 50 to 60 Hz
2×COM, 1×HDMI, 3×LAN, 2×USB2.0, 4×USB3.0
RS-232/RS-422/RS-485, Ethernet, Modbus TCP/RTU (master & slave),
PROFINET (optional), EtherNet/IP (optional)
TMflow (flowchart-based/script-based)
Classification, Object Detection, Segmentation,
Anomaly Detection, AI OCR
Positioning, 1D/2D Barcode Reading, OCR,
Defect Detection, Measurement, Assembly
Check
2D Positioning: 0.1
TM Landmark 3D Positioning (Working Point
away from Landmark 100/200/300
0.10/0.20/0.33
Auto-focused color camera with 5M resolution,
Working distance 100
Support Maximum 2×GigE 2D cameras
or 1×GigE 2D Camera + 1×3D Camera*
TM12S-M TM14S-X
33 kg 33.3 kg
14 12
1100 1300
+/- 360°
+/- 159° +/- 162°
130°/s
210°/s
225°/s
450°/s
+/- 0.03
6 rotating joints
IP54 (Robot Arm)
Typical 400 watts
24 to 60 VDC
CE, SEMI S2 (optional)
(1)
*
):
* (1)
~ ∞
(2)
TM12S-X
32.7 kg 33 kg
14 12
1100 1300
+/- 159° +/- 162°
IP54 (Robot Arm);
IP54 (Control Box)
N/A
