Figure 12: Pictorial view of TM14S / TM14S-M / TM14S-X Movement Range Diagram

Operator Position

Figure 13: Top View of TM14S / TM14S-M / TM14S-X Movement Range Diagram

Warning: Risk of crushing within
the operating area of the arm.
*All measures are in
Warning: Risk of collision within
the operating area of the arm.
.
