Figure 9: Pictorial view of TM12S / TM12S-M / TM12S-X Movement Range Diagram
Operator Position
Figure 10: Top view of TM12S / TM12S-M / TM12S-X Movement Range Diagram
Warning: Risk of crushing within
the operating area of the arm.
*All measures are in
.
Warning: Risk of collision within
the operating area of the arm.
