Robot Stick; Table 5: Specifications Of The Robot Stick; Figure 24: Securing The Ground Wire With Control Box; Figure 25: Waterproof Rubber Plugs Of The Control Box - Techman Robot TM12S Series Hardware Installation Manual

CAUTION:
⚫ Before any cable is plugged into the Control Box, replace the waterproof rubber plugs
at the base of the box with compatible cable glands.
Recommended cable gland: BG-48 (manufactured by KSS)
⚫

4.2.3.1 Robot Stick

The Robot Stick has 1 Power Button (combined with an indicator), 1 Emergency Stop button, 1 Reset
button, 1 Enabling Switch, 6 function buttons (Play, Pause, Stop, M/A, +, -), 3 light indicators and 1 set
of speed indicators. Their functions are defined as follow:

Figure 24: Securing the ground wire with control box

Figure 25: Waterproof Rubber Plugs of the Control Box

Dimensions
130.00×163.72×105.00
360g without cable
Weight
480g with 1-meter cable
IP Classification IP54

Table 5: Specifications of the Robot Stick
