Fuse holder
AC adapter
Line-out
Fieldbus (optional)
LAN
Debug port
Mic-in
HDMI
USB 3.0 *4
COM2
PE
USB2.0*2
Robot cable connector
LAN for GigE Camera*2
COM3

Figure 64: Interfaces of the TM12S / TM14S / TM12S-X / TM14S-X Series

Line-out
LAN
Mic-in
HDMI
USB 3.0 *4
COM3
COM2
USB 2.0*2
LAN for GigE Camera*2
Figure 65: Interfaces of the TM12S-M / TM12S-MX / TM12S-M SEMI / TM12S-MX SEMI / TM14S-M / TM14S-MX /
TM14S-M SEMI /TM14S-MX SEMI Series
IMPORTANT:
The control box of an M series robot should be mounted in a control cabinet with the protection
class of IP54 or higher.
