Installation Guide | iC7 Series Liquid-cooled System Modules
1
Figure 47: Connecting the Fieldbus Cable and the Fiber Cables
1
PLC (not included in the delivery)
3
Control board
5
Fiber cables

Installing the Control Cables into the Control Terminals

5.5
1.
Install the control cables into the control terminals.
See the pin numbering of the I/O and Relay Option in
1
2
3
Figure 48: Example of Installing the Control Cables
Danfoss Drives Oy © 2024.03
4
3
5
2
6
2
Fieldbus cable
4
Star coupler board
6
Power units
5.9 I/O and Relay Option
Connections.
AN389643231588en-000101 / 172F6360A |
43
