Installation Guide | iC7 Series Liquid-cooled System Modules
Table 18: Cable Sizes for AFE or GC Modules 525–690 V AC for Marine Applications (Marine cables according to IEC 60092-352) (continued)
Model code
iC7-60SLxx07-850AE00Fx
iC7-60SLxx07-945AE00Fx
iC7-60SLxx07-1040E00Fx
iC7-60SLxx07-1230E00Fx
iC7-60SLxx07-1325E00Fx
iC7-60SLxx07-1500E00Fx
iC7-60SLxx07-1700E00Fx
iC7-60SLxx07-1800E00Fx
iC7-60SLxx07-2000E00Fx
iC7-60SLxx07-2250E00Fx
iC7-60SLxx07-2500E00Fx
iC7-60SLxx07-2650E00Fx
iC7-60SLxx07-2940E00Fx
iC7-60SLxx07-3120E00Fx
iC7-60SLxx07-3600E00Fx
iC7-60SLxx07-3900E00Fx
iC7-60SLxx07-4320E00Fx
iC7-60SLxx07-4750E00Fx
iC7-60SLxx07-5040E00Fx
iC7-60SLxx07-5400E00Fx
iC7-60SLxx07-5750E00Fx
1) AM10L, AR10L, AM12L, or AR12L
Alternative Cable Sizes for Marine Installations, INU Modules 525–690 V AC
7.2.6
Table 19: Cable Sizes for INU Modules 525–690 V AC for Marine Applications (Marine cables according to IEC 60092-352)
Model code
iC7-60SLIN07-170E00Fx
iC7-60SLIN07-261E00Fx
iC7-60SLIN07-325E00Fx
iC7-60SLIN07-365E00Fx
iC7-60SLIN07-416E00Fx
Danfoss Drives Oy © 2024.03
(1)
Frame
2 x Ax12L
3 x Ax12L
4 x Ax12L
5 x Ax12L
6 x Ax12L
7 x Ax12L
8 x Ax12L
(1)
Frame
Ix10L
2
Mains cable Cu [mm ]
6x(3x95)
6x(3x95)
8x(3x95)
8x(3x95)
10x(3x95)
10x(3x95)
12x(3x95)
12x(3x95)
12x(3x95)
12x(3x95)
16x(3x95)
20x(3x95)
20x(3x95)
25x(3x95)
25x(3x95)
30x(3x95)
30x(3x95)
35x(3x95)
35x(3x95)
40x(3x95)
40x(3x95)
2
Motor cable Cu [mm ]
2x(3x70)
2x(3x95)
2x(3x95)
3x(3x95)
3x(3x95)
