Installation Guide | iC7 Series Liquid-cooled System Modules
Internal Cable Sizes for AFE and GC Modules, 525–690 V AC
7.2.3
Table 16: Bolt Sizes for the AFE and GC Modules
(1)
Frame
Ax10L
Ax12L
2 x Ax12L
3 x Ax12L
4 x Ax12L
5 x Ax12L
6 x Ax12L
7 x Ax12L
8 x Ax12L
1) AM10L, AR10L, AM12L, or AR12L
Field Cable Sizes for INU Module, 525–690 V AC
7.2.4
Table 17: Field Cable Sizes for INU Module, 525–690 V AC
Model code
iC7-60SLIN07-170E00Fx
iC7-60SLIN07-261E00Fx
iC7-60SLIN07-325E00Fx
iC7-60SLIN07-365E00Fx
iC7-60SLIN07-416E00Fx
iC7-60SLIN07-465E00Fx
iC7-60SLIN07-525E00Fx
iC7-60SLIN07-590E00Fx
iC7-60SLIN07-650E00Fx
iC7-60SLIN07-730E00Fx
iC7-60SLIN07-820E00Fx
iC7-60SLIN07-945E00Fx
iC7-60SLIN07-1060E00Fx
iC7-60SLIN07-1230E00Fx
iC7-60SLIN07-1400E00Fx
iC7-60SLIN07-1500E00Fx
iC7-60SLIN07-1640E00Fx
Danfoss Drives Oy © 2024.03
Bolt size for internal cable or busbar
M10
M10
M10
M10
M10
M10
M10
M10
M10
(1)
Frame
Ix10L
Ix12L
2 x Ix12L
Number of grounding terminals/bolt size
1/M8
1/M8
2/M8
3/M8
4/M8
5/M8
6/M8
7/M8
8/M8
2
Motor cable Cu [mm ]
3x120+70
3x185+95
3x240+120
2x(3x95+50)
2x(3x120+70)
2x(3x150+70)
2x(3x185+95)
2x(3x240+120)
2x(3x240+120)
3x(3x150+70)
4x(3x120+70)
4x(3x150+70)
4x(3x185+95)
4x(3x240+120)
4x(3x240+120)
8x(3x120+70)
8x(3x120+70)
AN389643231588en-000101 / 172F6360A |
2
Motor cable Al [mm ]
3x185+57
2x(3x95+29)
2x(3x120+41)
2x(3x150+41)
2x(3x185+57)
2x(3x240+72)
3x(3x150+41)
3x(3x185+57)
3x(3x185+57)
4x(3x150+41)
4x(3x185+57)
4x(3x240+72)
6x(3x150+41)
6x(3x185+57)
8x(3x150+41)
8x(3x150+41)
8x(3x185+57)
57
