Installation Guide | iC7 Series Liquid-cooled System Modules

Lift the system module to the required location.

Lifting the Filters

1.6

Use these instructions to lift the L Filter, the LC Filter, the dU/dt Filter, the dU/dt and Common-mode Filter, and the DC/DC Filter.

Put the lifting hooks in 4 holes at the top of the filter.

If necessary, lift the filter into a vertical position.

The recommended lifting angle is 60° ± 15°.

Figure 4: Example: Lifting the L Filter

Lift the filter to the required location.

45–75°

AN389643231588en-000101 / 172F6360A |
