Installation Guide | iC7 Series Liquid-cooled System Modules
Figure 26: The Mains Terminals and Grounding Terminal of AFE and GC, AR10L (left) and AR12L (right)
1
Mains terminal L1
3
Mains terminal L3
2.
Connect the mains cables to the corresponding mains terminals.
See the bolt sizes in
See the correct tightening torques in

Installing the Cables, INU (IR10L, IR12L)

4.5.3
1.
Find the motor terminals in the lower part of the system module. Notice the location of the U, V, and W terminals.
Figure 27: The Motor Terminals and the Grounding Terminal of INU, IR10L (left) and IR12L (right)
Danfoss Drives Oy © 2024.03
1
2
3
4
7.2.1 List of Cable Size Information.
7.1 Tightening
1
2
3
4
1
2
3
4
2
Mains terminal L2
4
Grounding terminal
Torques.
1
2
3
4
AN389643231588en-000101 / 172F6360A |
29
