Commissioning

6

Commissioning the System Modules

6.1
Follow these instructions to commission the drive.
Read the safety instructions in the Safety Guide and obey them.
1.
Make sure that the device connected to the drive output is installed correctly.
2.
Make sure that the drive and the device connected to the drive output are grounded.
3.
Make sure to select the mains cable and the output cables correctly.
For information on cable selections, see
4.
Make sure that the control cables are as far as possible from the power cables.
5.
Make sure that the shields of the shielded cables are connected to a grounding terminal that is identified with the grounding
symbol.
6.
Do a check of the tightening torques of all the terminals.
7.
Make sure that the cables do not touch the electrical components of the drive.
8.
Make sure that the common input +24 V is connected to an external power source.
9.
Make sure that the digital input ground is connected to your digital system ground when floating, or to the control terminal
ground.
10.
Check that the coolant inlets and outlets are connected according to instructions.
11.
Open the shut-off valves.
12.
Check the quality and quantity of the coolant.
13.
Make sure that the liquid circulation system operates correctly.
14.
Make sure that there is no condensation on the surfaces of the drive.
15.
Make sure that there are no unwanted objects in the installation space.
16.
Before connecting the drive to mains, check the installation and the condition of all the fuses and other protective devices.
For information on fuse selections, see
17.
Perform the insulation checks.
18.
Check the status of the LED indicators of the control board, star coupler board, and power unit.
PRE-CHARGING NEEDED
The system modules do not have an internal DC-link charging circuit. If the drive is connected to the supply voltage without first
pre-charging the DC-link capacitors, the inrush current can damage the equipment.
Before closing the main switch and connecting the drive to mains, pre-charge the DC-link capacitors of the system modules.

See the application guide for details.

