Dc Fuses For Inu 640-1200 V Dc, Ip00/Open Type - Danfoss iC7 Series Installation Manual

Installation Guide | iC7 Series Liquid-cooled System Modules
Table 23: DC Fuses for AFE or GC 640–1200 V DC, IP00/Open Type (continued)
(1)
Model code
iC7-60SL3A0x-5400E00Fx
iC7-60SL3A0x-5750E00Fx
1) For example, iC7-60SL3A07-236AE00F4
DC Fuses for INU 640–1200 V DC, IP00/Open Type
7.3.4
Table 24: DC Fuses for INU 640–1200 V DC, IP00/Open Type
(1)
Model code
iC7-60SLIN0x-170AE00Fx
(2)
iC7-60SLIN0x-206AE00Fx
iC7-60SLIN0x-208AE00Fx
(2)
iC7-60SLIN0x-245AE00Fx
iC7-60SLIN0x-261AE00Fx
(2)
iC7-60SLIN0x-302AE00Fx
iC7-60SLIN0x-325AE00Fx
iC7-60SLIN0x-365AE00Fx
(2)
iC7-60SLIN0x-385AE00Fx
iC7-60SLIN0x-416AE00Fx
iC7-60SLIN0x-465AE00Fx
iC7-60SLIN0x-525AE00Fx
iC7-60SLIN0x-590AE00Fx
iC7-60SLIN0x-650AE00Fx
iC7-60SLIN0x-730AE00Fx
iC7-60SLIN0x-820AE00Fx
iC7-60SLIN0x-945AE00Fx
iC7-60SLIN0x-1060E00Fx
iC7-60SLIN0x-1230E00Fx
iC7-60SLIN0x-1400E00Fx
iC7-60SLIN0x-1500E00Fx
iC7-60SLIN0x-1640E00Fx
Danfoss Drives Oy © 2024.03
Frame Rated Number
current of fuses
I [A]
L
8 x Ax12L 5400 32
5750
Frame Rated Number
current of fuses
I [A]
L
Ix10L 170 2
206
208
245
261
302
325
365
385
416
Ix12L 465 4
525
590
650
730
820
2 x Ix12L 945 8
1060
1230
1400
1500
1640
Fuse Part number
size
73 PC73UD12C900TF
Fuse Part number
size
73 PC73UD13C630TF
PC73UD13C800TF
PC73UD12C900TF
73 PC73UD13C800TF
PC73UD12C900TF
73 PC73UD13C800TF
PC73UD12C900TF
AN389643231588en-000101 / 172F6360A |
Fuse U Fuse I I
n n cp, mr
[V] [A] [A]
1200 900 10200
Fuse U Fuse I I
n n cp, mr
[V] [A] [A]
1250 630 5900
800 8900
1200 900 10200
1250 800 8900
1200 900 10200
1250 800 8900
1200 900 10200
65
