Fuses; List Of Fuse Size Information; Ac Fuses For Afe Or Gc 525-690 V Ac, Ip00/Open Type - Danfoss iC7 Series Installation Manual

Installation Guide | iC7 Series Liquid-cooled System Modules

Fuses

7.3

List of Fuse Size Information

7.3.1
This topic lists the links to find the fuse size tables for the system modules.
7.3.2 AC Fuses for AFE or GC 525–690 V AC, IP00/Open Type

7.3.3 DC Fuses for AFE or GC 640–1200 V DC, IP00/Open Type

7.3.4 DC Fuses for INU 640–1200 V DC, IP00/Open Type

7.3.5 DC-bus Fuses for DC/DC Converter, IP00/Open Type

7.3.6 Source DC+ Fuses for DC/DC Converter, IP00/Open Type

7.3.7 Source DC- Fuses for DC/DC Converter, IP00/Open Type

Table 21: Abbreviations Used in the Fuse Tables
Abbreviation
I
cp, mr
I
L
I
N
U
N
AC Fuses for AFE or GC 525–690 V AC, IP00/Open Type
7.3.2
Table 22: AC Fuses for AFE or GC 525–690 V AC, IP00/Open Type
(1)
Model code
iC7-60SLxx0x-236AE00Fx
(2)
iC7-60SLxx0x-261AE00Fx
iC7-60SLxx0x-300AE00Fx
(2)
iC7-60SLxx0x-325AE00Fx
iC7-60SLxx0x-334AE00Fx
iC7-60SLxx0x-380AE00Fx
iC7-60SLxx0x-425AE00Fx
iC7-60SLxx0x-475AE00Fx
iC7-60SLxx0x-530AE00Fx
iC7-60SLxx0x-595AE00Fx
iC7-60SLxx0x-670AE00Fx
iC7-60SLxx0x-760AE00Fx
62
| Danfoss Drives Oy © 2024.03
Frame Rated Number
current of fuses
I [A]
L
Ax10L 236 6
261
300
325
334
380
Ax12L 425 3
475
530
595
670
760
Description
Minimum required prospective short-circuit current at 5 ms pre-
arcing time. If there is a short-circuit fault in the common DC bus,
a multiplied I value is required.
cp, mr
Nominal current of the drive with low overload (110%). Allows a
+10% load variation for 1 minute every 5 minutes.
Nominal current of the fuse.
Nominal voltage of the fuse.
Fuse Part number
size
31 PC31UD69V250TF
PC31UD69V315TF
44 PC44UD75V12CTQ
Fuse U Fuse I I
n n cp, mr
[V] [A] [A]
690 250 2900
690 315 3600
750 1200 7200
