Installation Guide | iC7 Series Liquid-cooled System Modules
2
1
Figure 9: Mounting Holes of the System Module, AFE with the Integration Unit
1
Mounting holes in aluminum parts
3.
Attach the system module to the mounting brackets of the cabinet.
The mounting brackets are not included in the delivery.
14
| Danfoss Drives Oy © 2024.03
1
2
1
2
Mounting holes in sheet metal parts
AN389643231588en-000101 / 172F6360A
