Installation Guide | iC7 Series Liquid-cooled System Modules
Table 17: Field Cable Sizes for INU Module, 525–690 V AC (continued)
Model code
iC7-60SLIN07-1795E00Fx
iC7-60SLIN07-2080E00Fx
iC7-60SLIN07-2300E00Fx
iC7-60SLIN07-2460E00Fx
iC7-60SLIN07-2830E00Fx
iC7-60SLIN07-3050E00Fx
iC7-60SLIN07-3260E00Fx
iC7-60SLIN07-3500E00Fx
iC7-60SLIN07-4035E00Fx
iC7-60SLIN07-4400E00Fx
iC7-60SLIN07-4850E00Fx
iC7-60SLIN07-5300E00Fx
iC7-60SLIN07-5600E00Fx
iC7-60SLIN07-6100E00Fx
iC7-60SLIN07-6400E00Fx
1) IM10L, IR10L, IM12L, or IR12L
Alternative Cable Sizes for Marine Installations, AFE or GC Modules 525–690 V AC
7.2.5
Table 18: Cable Sizes for AFE or GC Modules 525–690 V AC for Marine Applications (Marine cables according to IEC 60092-352)
Model code
iC7-60SLxx07-236AE00Fx
iC7-60SLxx07-300AE00Fx
iC7-60SLxx07-334AE00Fx
iC7-60SLxx07-380AE00Fx
iC7-60SLxx07-425AE00Fx
iC7-60SLxx07-475AE00Fx
iC7-60SLxx07-530AE00Fx
iC7-60SLxx07-595AE00Fx
iC7-60SLxx07-670AE00Fx
iC7-60SLxx07-760AE00Fx
58
| Danfoss Drives Oy © 2024.03
(1)
Frame Motor cable Cu [mm
3 x Ix12L 9x(3x120+70)
9x(3x150+70)
12x(3x120+70)
12x(3x120+70)
4 x Ix12L 12x(3x150+70)
16x(3x120+70)
16x(3x120+70)
5 x Ix12L 15x(3x150+70)
20x(3x120+70)
6 x Ix12L 18x(3x150+70)
24x(3x120+70)
7 x Ix12L 28x(3x120+70)
28x(3x120+70)
8 x Ix12L 32x(3x120+70)
32x(3x120+70)
(1)
Frame
Ax10L
Ax12L
2
] Motor cable Al [mm
9x(3x185+57)
12x(3x150+41)
12x(3x150+41)
12x(3x185+57)
16x(3x150+41)
16x(3x185+57)
16x(3x185+57)
20x(3x150+41)
20x(3x185+57)
24x(3x150+41)
24x(3x185+57)
28x(3x150+41)
28x(3x185+57)
32x(3x185+57)
32x(3x185+57)
2
Mains cable Cu [mm ]
2x(3x70)
2x(3x95)
3x(3x70)
3x(3x95)
3x(3x95)
3x(3x95)
4x(3x95)
4x(3x95)
5x(3x95)
5x(3x95)
