Dc-Bus Fuses For Dc/Dc Converter, Ip00/Open Type - Danfoss iC7 Series Installation Manual

Installation Guide | iC7 Series Liquid-cooled System Modules
Table 24: DC Fuses for INU 640–1200 V DC, IP00/Open Type (continued)
(1)
Model code
iC7-60SLIN0x-1795E00Fx
iC7-60SLIN0x-2080E00Fx
iC7-60SLIN0x-2300E00Fx
iC7-60SLIN0x-2500E00Fx
iC7-60SLIN0x-2830E00Fx
iC7-60SLIN0x-3050E00Fx
iC7-60SLIN0x-3260E00Fx
iC7-60SLIN0x-3500E00Fx
iC7-60SLIN0x-4035E00Fx
iC7-60SLIN0x-4400E00Fx
iC7-60SLIN0x-4850E00Fx
iC7-60SLIN0x-5300E00Fx
iC7-60SLIN0x-5600E00Fx
iC7-60SLIN0x-6100E00Fx
iC7-60SLIN0x-6400E00Fx
1) For example, iC7-60SLIN07-140AE00F4
2) Only for B5 voltage class

DC-bus Fuses for DC/DC Converter, IP00/Open Type

7.3.5
Table 25: DC-bus Fuses for DC/DC Converter, Voltage Classes B5 and 07, IP00/Open Type
(1)
Model code
iC7-60SLDCxx-300AE00F4
iC7-60SLDCxx-360AE00F4
iC7-60SLDCxx-420AE00F4
iC7-60SLDCxx-480AE00F4
iC7-60SLDCxx-570AE00F4
66
| Danfoss Drives Oy © 2024.03
Frame Rated Number
current of fuses
I [A]
L
3 x Ix12L 1795 12
2080
2300
2500
4 x Ix12L 2830 16
3050
3260
5 x Ix12L 3500 20
4035
6 x Ix12L 4400 24
4850
7 x Ix12L 5300 28
5600
8 x Ix12L 6100 32
6400
Frame Rated Number
current of fuses
(I ) [A]
L
DR10L 300 2
360 2
420 2
480 2
570 2
Fuse Part number
size
73 PC73UD13C800TF
PC73UD12C900TF
73 PC73UD12C900TF
73 PC73UD12C900TF
73 PC73UD12C900TF
73 PC73UD12C900TF
73 PC73UD12C900TF
Fuse Part number
size (Mersen)
73 PC73UD13C630TF
73 PC73UD13C800TF
73 PC73UD12C900TF
73 PC73UD12C900TF
Fuse U Fuse I I
n n cp, mr
[V] [A] [A]
1250 800 8900
1200 900 10200
1200 900 10200
1200 900 10200
1200 900 10200
1200 900 10200
1200 900 10200
Fuse U Fuse I I
n n cp, mr
[V] [A] [A]
1250 630 5900
1250 800 8900
1200 900 10200
1200 900 10200
AN389643231588en-000101 / 172F6360A
