Installation Guide | iC7 Series Liquid-cooled System Modules
Table 25: DC-bus Fuses for DC/DC Converter, Voltage Classes B5 and 07, IP00/Open Type (continued)
(1)
Model code
iC7-60SLDCxx-720AE00F4
iC7-60SLDCxx-840AE00F4
iC7-60SLDCxx-960AE00F4
iC7-60SLDCxx-1080E00F4
iC7-60SLDCxx-1200E00F4
iC7-60SLDCxx-1440E00F4
iC7-60SLDCxx-1680E00F4
iC7-60SLDCxx-1920E00F4
iC7-60SLDCxx-2160E00F4
iC7-60SLDCxx-2400E00F4
iC7-60SLDCxx-2880E00F4
iC7-60SLDCxx-3240E00F4
iC7-60SLDCxx-3600E00F4
1) xx = B5 or 07

Source DC+ Fuses for DC/DC Converter, IP00/Open Type

7.3.6
Table 26: Source DC+ Fuses for DC/DC Converter, Voltage Classes B5 and 07, IP00/Open Type
(1)
Model code
iC7-60SLDCxx-300AE00F4
iC7-60SLDCxx-360AE00F4
iC7-60SLDCxx-420AE00F4
iC7-60SLDCxx-480AE00F4
iC7-60SLDCxx-570AE00F4
iC7-60SLDCxx-720AE00F4
iC7-60SLDCxx-840AE00F4
iC7-60SLDCxx-960AE00F4
iC7-60SLDCxx-1080E00F4
iC7-60SLDCxx-1200E00F4
Danfoss Drives Oy © 2024.03
Frame Rated Number
current of fuses
(I ) [A]
L
DR12L 720 4
840 4
960 4
1080 4
1200 4
2 x DR12L 1440 8
1680 8
1920 8
2160 8
2400 8
3 x DR12L 2880 12
3240 12
3600 12
Frame Rated Number
current of fuses
(I ) [A]
L
DR10L 300 3
360 3
420 3
480 3
570 3
DR12L 720 3
840 3
960 3
1080 3
1200 3
Fuse Part number
size (Mersen)
73 PC73UD13C630TF
73 PC73UD13C800TF
73 PC73UD12C900TF
73 PC73UD13C630TF
73 PC73UD13C800TF
73 PC73UD12C900TF
73 PC73UD13C800TF
73 PC73UD12C900TF
Fuse Part number
size (Mersen)
72 D72SG120V250QF
72 D72SG120V315QF
272 D272SG120V500QF
272 D272SG120V630QF
AN389643231588en-000101 / 172F6360A |
Fuse U Fuse I I
n n cp, mr
[V] [A] [A]
1250 630 5900
1250 800 8900
1200 900 10200
1250 630 5900
1250 800 8900
1200 900 10200
1250 800 8900
1200 900 10200
Fuse U Fuse I I
n n cp, mr
[V] [A] [A]
1200 250 1600
1200 315 2200
1200 500 3100
1200 630 4400
