Installation Guide | iC7 Series Liquid-cooled System Modules
A
2
1
Figure 50: Control Board Terminal Block and Terminal Numbering
A
Status indicators (FAULT, WARN, READY)
1
Control panel connector (X9)
3
24 V DC supply (X62)
5
RTC battery holder
7
Ethernet port (X1)
Table 3: STO Terminal Signals (X33) for the Inverter Module
Terminal
(1)
41A
(1)
41B
42
43
44
(1)
45A
(1)
45B
46
Danfoss Drives Oy © 2024.03
B
3 4 5
6
7
8
Function
24 V
24 V
S.INA+
S.INB+
S.FB+
GND
GND
S.INA-
0
B
Fieldbus indicators (ST, X1, X2) and Ethernet port
indicators (X0)
2
Fiber optic link to power unit (X80)
4
microSD card
6
Ethernet port (X0)
8
Ethernet port (X2)
Description
+ 24 V DC Output
+ 24 V DC Output
+ Safe Input Channel A
+ Safe Input Channel B
+ STO Feedback
0 V/GND
0 V/GND
- Safe Input Channel A
AN389643231588en-000101 / 172F6360A |
X33
41
41
42
43
44
45
45
46
47
48
X62
101 102
61 62
63 64
45
