Transmit Buffer

The transmit buffer stores the output data to be transmitted
before transmission. Default size is 1024 bytes.
The Feed Adjust part of the Setup Mode controls how much of
the media is fed out or pulled back before and/or after the actual
printing. These settings are global and will be effected regardless
of which program is run.
Note: The firmware uses the front edges of labels with gaps, the
ends of detection slots, and the forward edges of black marks for
detection, all seen in relation to the feed direction.

Start Adjust

The Start Adjust value is given as a positive or negative number of
dots (1 dot = 0.125 mm = 4.9 mils). Default value is 0, which
places the origin a certain distance back from the forward edge of
the copy.
• A positive start adjustment means that the specified length of
media will be fed out before the printing starts. Thus, the
origin is moved further back from the forward edge of the
copy.
• A negative start adjustment means that the specified length of
media will be pulled back before the printing starts. Thus, the
origin is moved towards the forward edge of the copy.

Stop Adjust

The Stop Adjust value is given as a positive or negative number of
dots (1 dot = 0.125 mm = 4.9 mils). Default value is 0, which
stops the media feed in a position suitable for tear off operation.
• A positive stop adjustment means that the normal media feed
after the printing is completed will be increased by the
specified value.
• A negative stop adjustment means that the normal media feed
after the printing is completed will be decreased by the
specified value.
