EasyCoder PF2i Bar Code Label Printer User's Guide (Fingerprint Version)
The detectable width of the black mark should be at least 5.0 mm
(0.2 inches) on either side of the LSS detection point.
⇐ ⇒
e Black Mark Length
Maximum: 21.3 mm (0.83 inches)
Common: 12.5 mm (0.5 inches)
Minimum: 5.0 mm (0.2 inches)
⇐ ⇒
f Black Mark Y-Position
It is recommended that you place the black mark as close to the
front edge of the ticket as possible and control the media feed, so
the tickets can be properly torn off.
Media Type Setup
• Ticket (with mark)
Note: Preprint that may interfere with the detection of the black
mark should be avoided. However, the Intermec Fingerprint
statement LBLCOND allows the sensor to be temporarily
disabled during a specified amount of media feed in order to
avoid unintentional detection, see Intermec Fingerprint manuals.
Note: The black mark should be non-reflective carbon black on a
whitish background. Do not allow any perforations to break the
edge of the media as this may cause the media to split and jam the
printer.
Appendix B — Media Specifications
141
