5.2 F M
ILTRATION
Set the duration and times for daily filtration.
The filtration timer has two cycles in any 24-hour period, Cycle 1 and
Cycle 2; these cycles are pre-set or are available for any setting
depending on the filtration mode selected.
When using 24/24 mode operation does not use timer cycles.
When using filtration cycles, it is recommended to keep at least 30min of time OFF between cycles. This
M o d e
There are 8 modes of operation:
In STOP mode, filtration timers are set to 00:00. The filtration will never run in
automatic mode.
In TIMER mode, filtration Cycle 1 and Cycle 2 times are set by the user.
In ECO+ mode, PoolCop adjusts filtration duration based on measured water
temperature, filtration rates, and other factors. This mode allows PoolCop to
automatically adjust the filtration duration based on changing seasonal and
weather conditions and thus protect water when temperature is high and save
energy if temperature is low.
Set Cycle 1 as desired. Duration will be taken into account when
o
calculating Cycle 2 duration.
Set the Cycle 2 Filtration ON time. PoolCop calculates and sets the OFF
o
time, with X indicated.
The duration is automatically calculated based on the average measured
o
temperatures during filtration in the last 24-hour period.
Other pool data settings, including pool volume and rate, are used to
o
correct calculated duration to ensure that adequate filtration is carried
out daily.
VOLUME mode is based on the same model as
difference:
In ECO+ Mode, the filtration duration is calculated is made using the pool
o
temperature.
VOLUME Mode does not take temperature into account, but simply use
o
the turnover rate defined in the Pool data menu to estimate the filtration
time.
In CONTINUOUS
so that the global filtration is 23/24. The only available setting is the starting
time of Cycle1.
In FORCE mode (24H, 48H or 72H) filtration will run 23/24 for the selected
period and will then revert back to the previous mode. Forced mode is achieved
by temporarily setting Cycle 1 timer value so that, added to Cycle 2, the
filtration duration is 23 hours. No timer settings are available in Forced mode.
In 24/24 mode, pump is running continuously, assuming that the pump is
correctly priming and pressure ABOVE Protection Pressure.
ECO+ Mode uses the daily average water temperature to calculate filtration duration. After a Factory Reset
the default filter time is approximately 8 hours, based on an assumed temperature of 20°C (68°F).
M
ODE ENU
will permit pH measurement, periodic filter cleaning, and automatic pool refill if installed.
mode, Cycle1 and Cycle 2 have the same 11:30 duration time
An updated calculation is performed automatically at 17:00.
P o o l C o p E v o l u t i o n M a n u a l : E V 4 4 M A N U S
> Mode
Cycle 1 ON
Cycle 2 ON
S E L E C T
NOTE:
ECO+ Mode with a noticeable
NOTE:
F I L T R A T I O N
: ECO+
: 02:30
OFF : 06:45
: 12:00
OFF 18:43 X
Text:
Default: STOP
Modes: STOP;
TIMER;
ECO+;
VOLUME;
CONTINUOUS;
FORCE24H;
FORCE48H;
FORCE72H;
24/24
Q U I T
