P o o l C o p E v o l u t i o n M a n u a l : E V 4 4 M A N U S
Installing the Feeder Pump
Install the feeder pump, associated suction and injection pipes and connectors as per the feeder pump installation manual.
Ensure that the correct liquid consumable pH- or pH+ is installed and secured.
Route the power supply for the feeder pump via an external Contactor.
The contactor will be operated by AUX 7 in the CCU.
Connect the feeder pump to the mains power supply as per the pump installation manual, ensuring electrical protection and
conformity.
Figure 48 - pH Feeder Pump Connection direct control
Test and prime the feeder pump:
In WATER AND
pH Control Programming
See 5.4.2.
Activating pH Control
In the MAINTENANCE menu, command the equipment to
P a g e | 3 8
TREATMENT, PH CONTROL, select priming ON.
MEASURE
Figure 49 - pH Feeder Pump Connection with coil
PH.
