Completing The Installation; Commissioning Poolcop - PoolCop Evolution Installer And User Manual

3.8 C
OMPLETING THE
Verify that all wiring has been done according to applicable electrical norms.
Verify that the pH+ORP electrode or blanking plug is secure, with O-Ring in place.
Verify that the power switch on the CCU is in the OFF position.
Close the CCU cover.
Connect the circuit breakers to the CCU and associated equipment.
3.9 C
OMMISSIONING
Switch the CCU ON.
The Power and 12VDC Supply LED's must illuminate.
o
If only the pump runs, disconnect the circuit breaker, switch ON the PoolCop and reset factory default
The PoolCop will display the following sequence:
Welcome note with firmware version (5 seconds).
o
Pump OFF.
o
FILTER position selected and valve might rotate to filter position.
o
Once filter position is confirmed, the main screen will be displayed.
o
Open all appropriate valves and remove any plugs in the filtration system.
Switch the pump ON from the
With the pump and filtration running, carefully check for leaks, especially in the following places:
pH+ORP sensor or blanking plug.
o
Seal between Valve Data Unit base and/or 2" Adapter and the multiport valve housing.
o
Filter connectors.
o
All valves and pipe connectors.
o
Verify correct functioning of auxiliaries by switching them ON/OFF in the
Close the CCU cover and secure with 4 tamper proof screws.
I
NSTALLATION
P C
OOL OP
If this equipment stays on for longer than 2 seconds, IMMEDIATELY switch OFF the CCU.
settings. Now reconnect the pump circuit breaker and continue with commissioning.
Repair all leaks and repeat the procedure, if required.
MANUAL CONTROL
P o o l C o p E v o l u t i o n M a n u a l : E V 4 4 M A N U S
CAUTION:
Recheck all connections.
CAUTION:
If leaks are found, switch OFF the CCU.
menu.
MANUAL CONTROL menu.
P a g e | 4 9
